Ultra-low-power sensor interface ASIC for industrial capacitive sensors

Ultra-low-power sensor interface ASIC for industrial capacitive sensors

This sensor interface ASIC reads out industrial accelerometers, pressure sensors and tilt sensors. It can be configured and optimized for specific applications using smart power techniques. Both its ADC resolution and sampling speed are user programmable. The sensor range can be any value between 100fF and 10pF.

FEATURES

  • Programmable sampling (6-b) between 2Hz and 125Hz
  • Configurable ADC resolution of 8, 9 or 10 bits
  • Current consumption of 2.4uA at 8-bits and 10Hz sampling
  • Enhanced CDS and chopping techniques
  • Ultra-low power class AB implementation
  • 0.5um CMOS technology
